The Panduit LAM2A1000-58-6Y is a heavy-duty aluminum mechanical lug designed for grounding and power distribution applications. Featuring a dual-barrel design, it accommodates two conductors ranging from 500 to 1000 kcmil, making it ideal for high-capacity terminations. The lug includes a single 5/8" stud hole for secure mounting and is built to NEMA specifications for hole size and spacing. Its tin-plated aluminum construction enhances conductivity and resists corrosion, while the non-insulated, free-hanging design allows for flexible installation.
Features
- Type: Mechanical lug with dual-barrel design
- Material: Tin-plated aluminum for improved conductivity and corrosion resistance
- Conductor Range: Accepts 500 to 1000 kcmil conductors
- Mounting: Single 5/8 inch stud hole
- Standards: Complies with NEMA hole spacing specifications
- Design: Free-hanging, non-insulated configuration
- Compliance: RoHS compliant
- Product Status: Obsolete (no longer in active production)
